2018 FORD F-150 5.0L COMPRESSED NATURAL GAS CONVERSION SYSTEM INSTALLATION INSTRUCTIONS
2018 F-150 5.0L INSTALLATION MANUAL
Page 34
CYLINDER - STANDARD COVER
NOTE: Perform a leak check rst before placing cover!!
1. Place the cylinder cover over the cylinder into nal position.
2. Mark locations on truck of the 4 holes on top of cover by window.
3. Remove cover from truck.
4. Drill 4 holes at previously marked hole locations with a 25/64” drill bit. De burr and rust proof any exposed metal.
5. Use rivet gun to insert the 4 rivet nuts.
6. Attached 6 u-nuts to cylinder base mounting plates.
7. Attach sticker (P/N: G-D0609), one on the inside of the cover and one on the cylinder strap closest to the valve.
8. Place cover back into place and secure with 6 1/4” - 20 x 1” bolts.
9. Center and place the Altech-Eco logo sticker on toolbox.
