#8400 Installation & Maintenance Manual - Pg. 15
3.0 — Parts Identification
3.4 — QC-50 - REFRIGERATION PARTS LIST
ITEM DESCRIPTION QUAN. PT. NO.
1. Large Condensing Unit 1 Cosp RWC700
2. Small Condensing Unit 1 Cosp RWC710
3. Filter Dryer 2 Cosp RWFD03
4. Sight Glass 2 Cosp RWSG02
5. Solenoid Valve 2 Cosp RWSV03
6. Solenoid Coil 2 Cosp RWSC02
7. Evaporator Coil 3 Cosp RWE221
8. Evaporator Fan Motor 4 MO-33385
9. Evaporator Motor w/blower and cage 2 MO-33386
10. Expansion Valve (1/2 ton) 3 Cosp RWEV30
11. Crankcase Pressure Regulator 1 Cosp RWCR01
3.5 — QC-50 CABINET & MISCELLANEOUS PARTS
ITEM DESCRIPTION QUAN. PT. NO.
1. Roll-in Cart 1 5814
2. Shelves 6 SH-22473
3. Front Grille Assembly 1 14704
4. Leg, Adjustable, 9" (229mm) 4 Cosp HLEG94
5. Door Switch Hardware Kit 1 14747
includes:
Handle Insert 1 HD-23084
Handle 1 HD-2934
Door Latch 1 LT-2935
Door Switch Magnet 1 MA-3739
Nut 1 NU-22285
Nut 1 NU-22286
Screw 1 SC-22280
Lock Washer 1 WS-22299
6. Door Hinge 3 Cosp HXHE02,217
7. Door Gasket 1 Cosp QGA60MV
8. Door Assembly (LH hinge) 1 Cosp QDA60SL
9. Door Assembly (RH hinge) 1 Cosp QDA60SR
