Alto 3.4 - Crossover Settings (Xover)

18
b. Centre Frequency / Cutoff Frequency
Peaking
Low Shelving High Shelving
Notch
c. Bandwidth
Allows to choose the width in octaves of the Peaking or Notch type curve. It s not used with Shelving
curves.
Peaking
Notch
d. Gain
Allows to control the boost or cut of the selected frequencies.
It's not used with the which has a fixed cut.Notch Filter,
Peaking
Low Shelving High Shelving
IN
A
EQ1
-5.0
kaeP
1.0
2k
00
IN
A
EQ1
-5.0
kaeP
1.0
2k
00
IN
A
EQ1
-5.0
kaeP
1.0
2k
00
Allows to choose the centre frequency of the Peaking curve and Notch filter, or the cutoff frequency of Shelv-
ing curves.
