││├0005-----------------------------
RA00356 fixed resistor 1/8W 1.2KΩ M type 1 R9
││├0006-----------------------------
RA00373 fixed resistor 1/8W 3.9KΩ M type 1 R8
││├0007-----------------------------
RA00375 fixed resistor 1/8W 4.7KΩ M type 1 R17
││├0008-----------------------------
RA00382 fixed resistor 1/8W 6.8KΩ M type 3 R1,R3,R11
││├0009-----------------------------
RA00386 fixed resistor 1/8W 10KΩ M type 6 R2,R4,R5,R7,R10,R12
││├0010-----------------------------
RA00390 fixed resistor 1/8W 15KΩ M type 5 R6,R15,R16,R18,R19
││├0011-----------------------------
HI00205 rotary switch SDB161PVB25FS-1-4-16-16PC 1 SW1
││├0012-----------------------------
RA00159 fixed resistor 1/4W 10Ω Mr type 1 R22
││├0013-----------------------------
RC00375 potentiometer B50KΩ R0911NOB-V1B503FN01-01 1 VR1
││├0014-----------------------------
CA00009 ceramic capacitor 22PF/50V NPO 5 C7,C19,C20,C23,C26
││├0015-----------------------------
CA00032 ceramic capacitor 330PF Y5E 1 C9
││├0016-----------------------------
CF00005 metal-film capacitor MSC 0.0022uF/63V 5% CASE01 1 C12
││├0017-----------------------------
CF00052 metal-film capacitor 0.0033uF/63V 5% CASE01 3 C5,C6,C16
││├0018-----------------------------
CF00014 metal-film capacitor MEC 0.01uF/400V 10% 1 C27
││├0019-----------------------------
CF00023 metal-film capacitor MSC 0.033uF/63V 5% CASE01 1 C8
││├0020-----------------------------
CH00017 laminated capacitor 0.1uF/50V Y5V PH5 2 C11,C15
││├0021-----------------------------
CB00137 electrolytic capacitor 2.2uF/100V φ5*11mm 1 C13
││├0022-----------------------------
CB00185 electrolytic capacitor 10uF/63V φ5*11mm 2 C28,C29
││├0023-----------------------------
CB00127 electrolytic capacitor 47uF/63V φ6*11mm 5 C1,C2,C17,C21,C22
││├0024-----------------------------
CB00151 electrolytic capacitor 220uF/63V φ10*16mm 1 C4
││├0025-----------------------------
CB00066 electrolytic capacitor 470uF/25V 105℃ φ10*16mm 3 C10,C14,C25
││├0026-----------------------------
CB00069 electrolytic capacitor 1000uF/6.3V φ8*11mm 1 C24
││├0027-----------------------------
SA00004 high speed diode 2A/100V BYV27-200,113 1 D1
││├0028-----------------------------
SA00105 zener diode 1W 12V 1N4742 4 ZD2,ZD3,ZD4,ZD5
││├0029-----------------------------
SA00051 L.E.D φ3 orange,green BOG303b 1 DL1
││├0030-----------------------------
SD00135 integrated circuit MC33079N 2 IC1,IC3
││├0031-----------------------------
SD00047 integrated circuit L4962/A 1 IC2
││├0032-----------------------------
HC00154 connector
2.54 180° 2*10P(gold-plated) 6/11.6mm
1 CN2
││├0033-----------------------------
HC00050 row-wire header 14PIN A28b-14B.T.6 1 CN1
││├0034-----------------------------
HI00162 push-button switch 2 paragraphs 6p PS-22E8552L 1 SW2
││├0035-----------------------------
HC00392 balance MIC jack-RS JY-5030-030G 180° 1 MIC2
││├0036-----------------------------
HC00582 balance MIC jack NCJ6FI-V (NEUTRIK) 1 MIC1
││├0037-----------------------------
TC00004 transformer SEV1924-03(EE-19) 1 L1
││├0038-----------------------------
CG00018 filter-EMI FILTER LF-22UH(WAH TAYI) 2 L2,L3
││├0039-----------------------------
NI02532 LED spacer support LEDS-22 22mm 2 DL1,DL2
││├0040-----------------------------
HA01934 jump 2mm 1 C18
││├0041-----------------------------
RA00399 fixed resistor 1/8W 27KΩ M type 1 R20
││├0042-----------------------------
SA00052 L.E.D φ3 round(green)long foot 26 1 DL2
││└0043-----------------------------
AC00179 tin without lead M705E Sn 3Ag-0.5Cu 40
│├0048-------------------------------
HK03801 PC board P-313121-1 1
││├0001-----------------------------
HB00854 PCB 313121-1_VER030318 1
││├0002-----------------------------
CF00014 metal-film capacitor MEC 0.01uF/400V 10% 2 C1,C2
││├0003-----------------------------
SA00094 rectifier diode 1N4002/100V 1 D2
││├0004-----------------------------
SA00007 bridge rectifier 8A KBU-806 comb type 1 D4
││├0005-----------------------------
HC00062 FUSE holder JEF-501L 8 F1,F2,F3,F4
││├0006-----------------------------
HC00324 connect terminal 6.5m/m (PC250) 5 S1,S2,S3,S4,S5
││├0007-----------------------------
HD00018 glass tube fuse
6.3A 250V φ5.2*20mm CCEE/CSA/S/UL/VDE
4 F1,F2,F3,F4
││├0008-----------------------------
MH00764 copper drill 2*4 2 D4
││├0009-----------------------------
HA02307 wire 6P 160mm 1
││└0010-----------------------------
AC00179 tin without lead M705E Sn 3Ag-0.5Cu 40
│├0049-------------------------------
NI02672 knob φ21*16mm 1
│└0050-------------------------------
HK05846 PC board P-313115-3-DIP-SR400A+ 1
│ ├0001------------------------------
SC00319 crystal oscillator 12.288MHZ 1 XT1
│ ├0002------------------------------
NE16149 lable SR400A+ CS:7EFA_V1.0 1
│ │├0001----------------------------
NI00034 membrane 0.045*1M 1
│ │└0002----------------------------
NH00014 bond paper 0.05*1M white 1
│ ├0003------------------------------
HC00145 connector
2.54 90° 2P(gold-plated) 6/14mm 1.2mm
1
│ ├0004------------------------------
HC00492 connector 20PIN B22-2*10BGA1 1 CN2
│ ├0005------------------------------
CB00166 electrolytic capacitor 100uF/16V φ6*5mm 1 C60
│ ├0006------------------------------
CB00069 electrolytic capacitor 1000uF/6.3V φ8*11mm 2 C62,C64
│ ├0007------------------------------
CB00201 electrolytic capacitor 47uF/25V φ6*7mm 8
C23,C24,C25,C26,C38,
│ ├0008------------------------------
CB00026 electrolytic capacitor 10uF/50V φ6*7mm 2 C55,C56
│ ├0009------------------------------
SG00341 SMD integrated circuit
EN29LV040-70JC/SR400A+ CS:7EFA
1 IC2
│ │└0001----------------------------
SG00337 integrated circuit EN29LV040-70JC(PLCC32)/(EON) 1
│ ├0010------------------------------
HK04891 PC board P-313115-3-SMD-ALTO 1
│ │├0001----------------------------
SG00069 SMD integrated circuit MAX709L-CSA 1 IC5
│ │├0002----------------------------
SF00009
voltage stabilized transistor
LM1117MP-3.3 (3.3V, SOT223) 1 IC9
│ │├0003----------------------------
RD00068 SMD fixed resistor 1/10W 100Ω ±5% 0603 4 R1,R29,R30,R39
│ │├0004----------------------------
RD00076 SMD fixed resistor 1/10W 330Ω ±5% 0603 1 R49
