Alto TYPHOON SERIES User Manual

TYPHOON PS 16.24
+18V -18V +12V
+48V
Typhoon series power supplyTyphoon series power supply
1: INTRODUCTION
In order to reduce the interfere caused by the power supply, Typhoon series mixing console are equipped with
professional external power supply, which has two modes: TYPHOON PS 16.24 for TYPHOON 1600, TYPHOON
2400 and TYPHOON PS 32.48 for TYPHOON 3200, TYPHOON 4800. The main difference between these two
external power supplies depends on the power. The power of TYPHOON PS32.48 is more than TYPHOON.
PS16.24
2: CONTROL ELEMENTS AND FUNCTIONS
POWER LED
There are four LEDs, each one indicates its relative power of the power box. The power supply won't work normally
untill all these LEDs light up.
AC INPUT
It allows to connect to the main power. Please make sure that the local voltage matches the voltage of the unit
requires before connecting the unit to the main power.
POWER SWITCH
It switches ON/OFF the unit main power.
DC POWER OUTPUT
It is supplied DC power for TYPHOON series mixing console.
Note: Dangerous voltage, please don't touch. Please use the special power cord we attached.
DC OUTPUT
AC INPUT
POWER
ON
OFF
1
1
2
3
4
2
3
4
2
