Altronix AL1002ULADAJ - Page 6

- 6 - 02 ULADA Application Guide
1.5”
(38.1mm)
1.5”
(38.1mm)
4.615” (117.2mm) 4.615” (117.2mm)
1.5”
(38.1mm)
1.5”
(38.1mm)
4.615” (117.2mm) 4.615” (117.2mm)
1.75”
(44.5mm)
1.75”
(44.5mm)
1.375”
(34.9mm)
1.125”
(28.6mm)
1.5”
(38.1mm)
1.5”
(38.1mm)
5.0” (127.0mm) 5.0” (127.0mm)
4.5” (114.3mm)4.5” (114.3mm)
1.25”
(31.8mm)
1.25”
(31.8mm)
0.79” (20.1mm)0.91”
(23.1mm)
0.91”
(23.1mm)
15.5” (393.7mm)
1.1” (27.9mm)
1.1” (27.9mm)
1.1” (27.9mm)
12.23” (310.6mm)
2.0”
(50.8mm)
2.0”
(50.8mm)
1.25” (31.8mm)1.25” (31.8mm)
AL602ULADA, AL802ULADA, AL1002ULADA
Enclosure Dimensions (BC400):
15.5” x 12” x 4.5” (393.7mm x 304.8mm x 114.3mm)
