- 4 - AL600ULX Series
Door
CAUTION: De-energize unit prior to servicing. For continued protection against risk of electric shock and
fire hazard replace fuse with the same type and rating. Do not expose to rain or moisture.
Wire
Strap
(from
Enclosure
to Door)
Battery & AC
Supervision
Circuit
(power-limited)
Class 1
Power
Distribution
Module(s)
INPUT
Divider
Earth
Ground
+ DC ---
BAT FAIL
NC C NO NC C NO
+ BAT ---
AC FAIL
DCAC BAT
LG N
5A 250V
AC Delay
Battery
connection
(non power-limited)
(non power-limited)
CAUTION: Optional rechargeable stand-by batteries must match the
power supply output voltage setting.
Keep power-limited wiring separate from non power-limited.
Use minimum 0.25" spacing.
Optional Rechargeable
Stand-by Battery
Optional Rechargeable
Stand-by Battery
SW1
OFF - 24V
ON - 12V
ON
OFF - 24V
ON - 12V
ON
115VAC power mains
non-power limited
Fig. 1
Fig. 1a
Fig. 1b
