Altronix NetWay8 User Manual

- 6 - NetWay8/NetWay16
NetWay8/NetWay16 Rack Mount Chassis Mechanical Drawing and Dimensions:
Fig. 6
The lightning flash with arrow head symbol within an equilateral triangle is intended to alert the user to the
presence of an insulated DANGEROUS VOLTAGE within the product’s enclosure that may be of sufficient
magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important oper-
ating and maintenance (servicing) instructions in the literature accompanying the appliance.
CAUTION: To reduce the risk of electric shock do not open enclosure. There
are no user serviceable parts inside. Refer servicing to qualified service personnel.
8.5"
(215.9mm)
0.75"
(19.05mm)
19.125"
(485.77mm)
17.625"
(447.67mm)
1.625"
(41.27mm)
AC POWER
(ON)

Altronix NetWay8 Specifications

General

Brand	Altronix
Model	NetWay8
Category	Network Hardware
Language	English
