- 20 -
Instruction for montage of outside roller shutters in
ADAPTING system, type SK
and in
ADAPTING system, type SK with MOSKITO.
SK_+_moskito_m_uk
We reserve the right to any technical change. Valid on: 2009-06-02
119
120
123
122
121
k) Close [119] and screw the shutter box (base part) [120].
l) Adjust the “location” of the mosquito net’s endslat, by placing the side lock’s nest on the appropriate height (in each guide
channel) and then screw tightly with suitable strength [121], [122]. Lower the mosquito net and check, if the surface be
tween endslat and window frame is sealed up by the brush [123].
