Your heater should be checked once a year by a qualied
technician. Take special care to retighten any xtures or nuts and
bolts that have come loose.
5. Place the 3 post brackets into
position on the base. Use three
M8 x 16mm bolts to join the
post brackets to the stand.
(Figure C)
6. Place the post on top of the
3 post brackets. Use six M6
x 35mm bolts and nuts to
connect the post to three post
brackets. Tighten the bolts and
nuts securely. (Figure D)
Fig.C
