7. Place the tank housing over
the stand and down onto the
weighted foot piece. (Figure E)
8. Take the burner head with the
attached hose and feed the
supply hose through the hollow
centre of the post.
Secure the assembled burner
head unit to the top section of
the post using four M6 x 10mm
bolts; ensure that the warning
and ignition instructions are
positioned with the control /
ignition valve selector knob
both in view.
Attach the supplied regulator to
the hose end.(Figure F )
4
Fig.E
