Alvey REEF QUEEN - Page 2

14WC2M - REEF QUEEN
Key
Part
Description
Key
Part
Description
1
D1A-RQ
Stainless Steel Body
14
D7A-RQ
Drag Wheel & Bush
2
D1B-RQ
Over Run Bar
14A
D7G-RQ
Star Nut Bush
3
D1C-RQ
Side Bushes (Pair)
15
D7B-RQ
Drag Washer - Metal (Full set of 10)
4
D3A-RQ
Guide Assembly
16
D7C-RQ
Drag Washer - Fibre (Full set of 10)
5
D3B-RQ
Guide Roller Assembly
17
D7D-RQ
Star Adjusting Nut
6
D4E-RQ
Stainless Steel Arm Only
18A
D7E-RQA
Handle Plate with Spindle Only
7
D4A-RQ
Spool Only
18B
D7E-RQB
Handle Plate Only
8
D4B-RQ
Spool & Washers
19
D7F-RQ
Handle Plate Lock Nut (each)
9
D4D-RM
Handle Only
20
D7J-RQ
Drag Pawl
10
D4E-RM
Handle Screw
21
D7K-RM
Grease Nipple
11
D4F-RM
Handle Assembly
22
D7L-RQ
Drag Retainer Plate
12
D4G-RM
Handle Lock Nut
23
D7M-RM
Spool Stud Nut & Washer
13
D4H-RM
Felt Plug
24
D7Q-RQ
Belville Washers (Pair)
