APPENDIX D: COMMUNICATIONS
IS-300CA INVERTER POWER SUPPLY
D-22 990-418
IS-300CA Advanced / EtherNet/IP
TM
: Screen 08 FORCE SETUP screen Specific data in accordance
with Schedule No. (Schedule No.: 001 to 255)
Example of data writing:
#01W001S08:1,02000,02100,02200,02300,02400,02500,1,0,0,00000,0[CR][LF]
Item Contents
Character
String
Range
1*
1
STEP MODE n, 0:OFF 1:ON
2 PROPVALVE# n, 1 to 2
3 SQD FORCE nnnnn,
00000 to 35000(N)
00000 to 03569(kgf)
00000 to 07868(lbf)
4 SQZ FORCE nnnnn,
5 WELD1 FORCE nnnnn,
6 COOL1/WELD2 FORCE nnnnn,
7 COOL2/WELD3 FORCE nnnnn,
8 HOLD FORCE nnnnn,
9*
1
VALVE# n, 1 to 4
10 FORGE VALVE# n, 1 to 2
11 CHAINING n, 0:OFF 1:ON
12 SUCCESSIVE n, 0:OFF 1:ON
13 FORGE DELAY nnnnn, 00000 to 30000(ms)
14 FORGE MODE n 0:OFF 1:ON
*1 Items inhibited from setting (When setting data, omit these items.)
“,” is not transmitted, too.
