Top View
Bottom View
Complete Installation
1. Insert the foam seal behind the top of the lower window sash
and against the glass of the upper window.
A. Top of lower window sash
B. Foam seal
5. Use a ¹⁄₈” drill bit to drill a starter hole through the bottom hole
in the side curtain and into the window frame.
6. Insert one of the ³¹⁄₃₂” screws through the bottom hole of the
left-hand curtain and into the window frame.
7. Repeat for the right-hand curtain.
2. Place the window lock bracket as shown. Use a ¹⁄₈” drill bit to
drill a starter hole through the hole in the window lock bracket
and into the upper window.
3. Attach the window lock bracket to the upper window with one
³¹⁄₃₂” screw to secure the window in place.
4. Plug into a grounded 3 prong outlet.
5. Press RESET on the power supply cord. See “Electrical
Requirements.”
8 9
