Features
1
2
3
4
5
6
7
3
1 Door Handle
Ergonomically designed for one handed operation.
2 Unit Serial Number
Located on the lower left hand side and back of the
oven.
3 Air Filters
The oven has two air lters. Each are located on
the lower sides of the oven. To remove, simply slide
out.
4 Display
Display provides user interface.
5 ON/OFF Pad
Use to turn on and shut oven off.
6 Keypad
Use for time input, programmed pads and data
input.
7 USB Port / Protective Cover
The oven is equipped with an USB Data Port. Use
with standard ash drives.
To program the oven using standard ash drive:
Oven must be in Off mode (Preheat must be OFF)
1. Remove protective cover from bottom of keypad.
2. Insert the ash drive into the slot located below the keypad.
3. From Off, press and hold the “2” pad to go to “User Options”.
4. Go to Option #17 by pressing “Back ” or repeatedly pressing “Enter ”
5. Select the desired operation by highlighting “Transfer card to oven
” or “Transfer oven
to ash drive
” with the Scroll Up or Scroll Down keypad.
Note: After inserting ash drive in USB port wait at least 6 seconds before proceeding to Step 6.
6. Press the “Program
” pad to begin the transfer (The screen will indicate”TRANSFERRING” and indicate
“DONE” when transfer is complete.) Note: The screen will indicate “
NO CARD” if the data key is not
detected.
7. Remove ash drive and close the protective cover.
