987 Remove from sprues P19, P20 the plastic components for assembling the Arado: fuselage
2584; two oats 2585, wings 2586, 2587, motor 2588, rudder 2589.
992 Insert in the holes of oats 2585 the dowels of the support diagonals 1478, 1479;
check that they are parallel to each other; then glue.
989 With a ne drill bit, go over the holes indicated by the red arrows:
under fuselage 2584, on oats 2585 and on wings 2586, 2587.
991 Remove the sled and insert two supports 1478, 1479 into the four front dowels
under the fuselage. Orient the wings of piece 1479 towards the nose, those of piece
1478 towards the tail; then glue them in place.
988 Take the support diagonals of oats 1478, 1477 which you can nd on sheet
1564 and bend the side aps of the two supports upwards. With a ne drill bit, go
over the three holes on motor 2588 for assembling propeller blades 1479 which you
can nd on sheet 1564. Insert them diagonally into the holes as shown in the detail
above; then glue.
990 Temporarily insert the dowels of the sled structure of the catapult prepared in
step 986 into the three lower holes of fuselage 2584, orient the pieces correctly and
do not glue.
