AMAV MICRO20 - Macro80 P Power Supply

CN4
TO CN
9 OF PRE.AMP. PCB
D2
D1
1N4007x2
D3
1N4007x2
D4
+
C10
10uF,50V
+
C9
10uF,50V
D6 1N4007
+
C8
10u,25V
+
C7
10u/25V
1
2
3
U1
7812
2
3
1
U2
7912
D5
1N4007
+
C6
+
C5
6800u/50V
C4C3
C2
C1
.1uF(X4)
BR1
CN3
CN2
CN1
TO PN3 OF POW.AMP. PCB
TO SUB WOOFER PCB
CN
6
+V
-V
GND
TO POW. AMP PCB
+12V
G
A
+12V
G
B
FROM TXFR
6800u/50V
REV- 0 DATED-17.05.07
+12V
-12V
G1
G2
Australian Monitor
Macro80P Power Supply
