34
EN
General
Power supply: 3 x 1.5V AAA
Battery life: approx. 30h
(Flashlight on),
approx. 100 h
(Flashlight off)
Max. measurement
voltage:
CAT II: 1000 V
Cat III: 600 V
Pollution degree: 2
Clamp jaw opening: approx. 1.3" (33mm)
Display: 6000 counts backlit
LCD
Measurement rate: 3 readings per second,
nominal
Temperature sensor: Type-K thermocouple
Input impedance: 10MΩ (V and V~)
AC response: True rms (A~ and V~)
ACV bandwidth: 2kHz
Operating temperature: 41 °F to 104°F
(+5 °C to +40°C)
Storage temperature: –4 °F to 140 °F
(–20 °C to +60 °C)
