TIPS FOR MOUNTING ON THE WALL
• Consider the height of everyone using the device.
We recommend placing the device at eye level.
• Make sure there’s enough room to mount the device
in both orientations.
• Don’t drill holes over studs, electrical wiring or piping.
• Before mounting, unplug the device from electrical
socket and keep it away from water.
TOOLS YOU’LL NEED
Electric drill
• 8 mm (or 5/16")
• Phillips #2 driver bit
Hammer
Spirit level or level app
Wall-safe tape
ALSO IN THE BOX
Wall mount Power adaptor 4 x Anchors
4 x Screws
Mounting template
sized to the device
40.2 x 25.2 cm (15.8" x 9.9")
Included screws and anchors are recommended for plasterboard, brick, concrete or tile surfaces.
BEFORE MOUNTING YOUR DEVICE
Volume
Mic/Camera on/off
Camera cover
Camera
Microphones
BACK
Power port
Wall mount slot
M E E T YO U R ECHO SHOW 15
The device can be placed in
landscape or portrait orientation.
1 2
