11
Battery and charging
Charging
• Slide the battery(H) into the battery slot until it locks.
• Connect the charger(I) to the charging port(9).
• Connect the charger(I) to the socket outlet.
• The battery status indicator(12) shows the charging status:
Battery status indicator Status Charging level
1 LED flashing Charging Low
2 LEDs on/flashing Charging Medium
3 LEDs on/flashing Charging High
All LEDs off Charging finished Fully charged
• When the battery(H) is fully charged, disconnect the charger (I) from the charging
port(9) and then from the socket outlet.
NOTICE
While charging, the product cannot be switched on.
Installing/removing the battery
• To remove: Push both battery release buttons(10) and pull out the battery(H)
backwards.
• To install: Slide the battery(H) into battery slot until it locks.
1
2
3
