7
Operation
Functions
• Forward button (D): Press this button to view the next page in your Internet browser.
• Backward button (F): Press this button to view the previous page in your Internet browser.
• Left button (B): Performs left click function according to the computer settings.
• Right button (A): Performs right click function according to the computer settings.
• Scroll wheel (C): Moves up/down on the computer screen. Offers a third click function
according to the computer settings.
• ON/OFF switch (H): Switches the mouse on and off.
• DPI button (G): Toggles between three DPI settings: 800 DPI, 1200 DPI (default) and 1600 DPI.
The indicator light (E) flashes once for 800 DPI, twice for 1200 DPI and 3 times
for 1600 DPI.
Features
• Multi-level intelligent power-saving: This feature limits the current consumption based on the
duration for which the product is idle. The product enters one of the three levels of sleep mode
that allow power-saving. This is listed in the table below:
Product idle for Sleep mode Current consumption
1 second First-class; move the product
to wake it
< 0.3 mA
45 seconds Second-class; move the
product to wake it
< 0.2 mA
8 minutes Third-class; press any button
or move the scroll wheel to
wake it
< 30 uA
The sensor LED goes off in the third-class sleep mode.
• Low-voltage indicator: At low-voltage (between 1.9 V and 2.1 V), the indicator light (E)
continuously flashes 10 times and then goes out. This suggests that the batteries need to be
replaced. The product continues to operate. However, when the voltage falls below 1.9 V the
product will stop operating.
