PARAMETER
DEFAULT
STATE
Narrow
Band Measurement
Type
VERY WIDE BP
Front Panel
Special Amplitude Display
OFF
Front
Panel
Special Frequency Display
OFF
Amplitude
Display
Units
Operating
Mode
FLOATING
Amplitude
Display
Decimal
Operating
Mode
FLOATING
Frequency
Display
Decimal
Operating
Mode
FLOATING
PGA
Operating
Mode
AUTO
PGB
Operating
Mode
AUTO
PGC
Operating
Mode
AUTO
SVF
Tuning
Mode
HOLD
Detector
Speed
Mode
AUTO
Numeric
Entry
Mode
SOURCE AMPLITUDE
IMD
Mix
Ratio
(requires option
002)
1:1
'
Measurement Mode
FREE
RUN
Relative
Measurement Enable
OFF
Measurement
Type
WIDE BAND
Output
B
(requires option
007)
OFF
.
Power
amp
source
select
INTERNAL
Absolute Units
V
Output Configuration
A
ONLY
Output
Enable
OFF
Programmed
Source
Amplitude
0.0
V
DC
Range (requires option 008)
100
V
Phase Scale
(requires option
009)
z
180
DC Volts Measurement
Mode
(requires
option
008)
OFF
Phase Measurement
Mode
(requires
option 009)
OFF
DC Feedback
(requires option
008)
FULL
DC
DAC
A
(requires option
008)
0
DC DAC
A
(requires option 008)
0
DC
Multiplexer (requires
option 008)
OUTPUTS OFF
DC
Digital Utility
(requires option 008)
0
