1234567 16A
L1 N1 N L
Sensor
Max load 16A (3600W)
Error Codes
This relates to a fault with the internal temperature
sensor, either through damage or disconnection.
This usually requires a replacement thermostat
to correct.
This relates to a fault with the external oor
sensor probe. Contact your electrician, who
can isolate the electricity supply and check the
sensor is connected and working correctly.
Screen Lock
In some situations where your Amber-Pro is
installed into a location where restricted access
is necessary, simply:
Press and hold the button until the
appears on the screen (3 seconds).
To unlock, simply repeat the process until the
disappears.
E1
E2
3 Simple Steps to Factory Reset
1. Having initiated the advanced settings, tap the
menu button continuously until you see 12
2. Use the and buttons to set to 01
3. Press the buttons and switch o at the
mains to complete factory reset
No. Description Default Range
00
Room
temperature
calibration
00 -10~10 C
01
Floor
temperature
calibration
00 -10~10 C
02 Sensor mode 00
00: built-in sensor
01: oor sensor
02: both sensors
03
Max
temperature
setting
35 C 30~60 C
04
Min
temperature
setting
5 C 5~15 C
05
Switching
dierential
1 C 0~10 C
06
Frost protection
mode
00 00:yes 01:no
07
Heating
schedule
00
00: 5/2 day mode
01: 6/1 day mode
02: 7 day mode
08 Output delay 00 0~10s
09
Maximum oor
temperature
35 C 5~60 C
10
Holiday
temperature
Not Used Not Used
11
Temperature
unit
00 00: ˚C 01:˚F
12 Factory reset 00 00:no 01:reset
Advanced Settings Overview Dimensions
86mm
14mm
30mm
86mm
Installation Guide
STEP 1
Mount the backing plate in the wall socket
with a screwdriver before wiring takes place.
1234567 16A
L1 N1 N L
Sensor
Max load 16A (3600W)
1234567 16A
L1 N1 N L
Sensor
Max load 16A (3600W)
STEP 2
Ensure all wiring is undertaken by a qualied
electrician.
STEP 3
After connecting the wires, mount the
thermostat onto the backing plate as per
pictures.
