8a. L-300 AMPLIFIER FEATURES (Without Streamer)
1. Bluetooth Antenna (1)
2. Bluetooth Switch
3. Bridge (70V) or Stereo Switch
4. Low Pass Filter (LPF) Switch
5. Gain Knob
6. Clipping/BT Indicator Lights
7. Speaker Output: Right
8. Speaker Output: Left
9. 120V AC Input
10. Fan
11. Bridge (70V) Speaker Output
L+ & R-
12. Line OUT Phoenix Connection
13. Line IN Phoenix Connection
14. USB 5V Power Port
15. -
16. -
17. Speaker Wire Strain Reliefs (2)
18. Weather Resistant Enclosure
19. Mounting Tab
20. Bottom Panel Access Door:
(For easier access, loosen the
2 forward screws on each side &
then pull panel downward)
1.
5.
20.
20.
10.
17.
17.
2.
3.
MANUFACTURED IN CHINA
SERIAL BARCODE
SERIAL NUMBER
BRIDGE (70V)
LEFT + RIGHT -
11.
