DIAGRAM • S11BP Subwoofer Burial Installation
8.46 in
15.75 in
2-4 in
23.65 in
17 inch
12.09 in
5 in
9c. POSITIONING & INSTALLING THE AMPLIFIER
Locate a shaded area for the amplifier to be installed out of direct
sunlight.
Mount amplifier to a wall or post located in a shaded area.
Use a minimum of 14 AWG wire for sending a strong signal.
Do NOT Turn ON Amplifier until all Wiring is Complete
To Next Page
