Numerical keys0~9
PRESET
DIRECT
TUNE and TUNE
MEMORY
AUTO
MANUAL
PRESET
SELECT, INFO, MONO
TIME, PROGRAM, TEXT, TYPE
The numbered keys perform several
functions when combined with PRESET
and DIRECT buttons. See below:-
When this button is pressed, the
numbered keys can be for direct access to
each stored preset service-station.
Presets 1-9 are displayed as P01, P02,
P03, and so on. To select service-station
presets 10~30 for AM/FM module or 10 for
FM+ of DAB/DAB+/FM+ module, press
the tens place key first. For example, to
select 26, first press key 2, then press key
6.
When this button is pressed, the
numbered keys can select the broadcast
frequency of the station you wish to
receive. First press the DIRECT key, then
the numbered keys corresponding to the
station. In USA: to receive FM 103.7,
press DIRECT, 1, 0, 3, 7, 0. IN Europe: to
receive 103.75, press the DIRECT key,
then press keys 1, 0, 3, 7, 5. Note if you
enter an incomplete frequency, such as 1,
0, 3, 7 which is missing the final 0 or 5,
there will be a short pause while the XTad
fills in the missing number and finds the
station.
Tuning up or down the DAB/DAB+/FM+/
FM service-stations is accomplished by
pressing either of the two TUNE buttons.
Press the button to tune toward higher
frequencies or the button to tune toward
lower frequencies.
When you set or listen to a service-station
and want to put into memory as Preset
service-station, you can press the
"MEMORY" key and key in Preset # you
want to put the service-station in by
numerical keys. The display will show Pxx
right away.
Press this button to activate AUTO TUNE.
([A] on display)
Press this button to activate MANUL
TUNE. ([M] on display)
Press this button to activate PRESET. ([P]
on display)
The same as the buttons on front panel.
Please refer to Front Panel Control.
These buttons are for RDS of FM and
FM+. Press each key to display TIME,
PROGRAM, TEXT, TYPE on displays.
9
