MTR-INS-018/01-03 January 2003
4
APPLICATION. These meters are for use in the measurement of potable cold water up
to 120 degrees F and working pressures up to 150 psi.
P
ERFORMANCE DATA DIMENSIONS
Model Size Flow Range
Recommended
Continuous
Flow
Length Width Height
(Lid
Closed)
Weight
5/8” x 1/2” 1/8 – 20 15 7 1/2 4 5 1/2 3 1/2
5/8” x 3/4” 1/8 – 20 15 7 1/2 4 5 1/2 3 1/2
3/4” x 3/4”S 1/4 – 30 15 7 1/2 3 7/8 6 3/16 4 3/5
3/4”x3/4” 1/4 – 30 15 9 3 7/8 6 3/16 4 4/5
3/4”x1” 1/4 – 30 15 9 3 7/8 6 3/16 4 4/5
1” 1/2 – 50 25 10 3/4 6 15/16 6 5/8 10 1/5
1 1/2” 1 1/2 – 100 50 12 5/8 or 13 7 1/2 or 8 1/2 8 7/8 21 7/10 or 23 7/10
C700
2” 2 – 160 80 15 1/4 or 17 8 3/4 8 1/8 36 7/10 or 38 7/10
1 1/2” 3 – 200 160 10 7 3/8 7 3/4 19 1/2 or 20
2” 3 – 200 160 10 7 3/8 7 3/4 21 1/2 or 22
3” 4 – 750 600 11 7/8 7 3/8 11 7/8 33 3/8
4” 7 – 1250 1000 14 9 10 3/4 51 1/2
6” 15 – 2500 2000 18 11 13 3/8 90
8” 25 – 3500 2800 20 13 7/16 16 1/16 168
10” 55 – 5500 3200 17 3/4 16 1/8 18 15/16 246
T3000
12” 95 – 7000 4300 19 3/4 19
1/16 20 3/8 278
2” 1/4 – 160 100 17 12 9/16 8 34
3” 1/4 – 650 325 17 13 1/4 9 7/16 55 1/4
4” 1/4 – 1150 575 20 14 1/8 10 7/8 67 1/8
6” 3/4 – 2500 1560 24 17 9/16 8 1/8 145
C3000
8” 1 1/2 – 3000 1875 34 or 34 1/2 20 1/2 16 227 or 285
H3200 3” 5 – 400 300 14 3/8 7 3/8 8 13/16 17 1/4
