Chapter 3
Display Configuration
This section describes how to configure displays and lists available display
connections for your graphics card.
3.1 AMD Radeon™ HD 7790 Connections
The following figure shows the display connections available on your AMD Radeon™
HD 7790 graphics card.
Note: The baseplate may not appear exactly as depicted.
Figure 3–1 AMD Radeon™ HD 7790 Display Connections
1 DisplayPort (DP+) connection. Carries video and audio signals to DisplayPort-
compliant devices.
2 HDMI™ connection (Type A). Carries video and audio signals to HDMI-
compliant devices.
3 Dual-link DVI-I connection. Provides video digital signals and HDMI output
that is compatible with most HDMI-compliant devices.
4 Dual-link DVI-D connection. Provides video digital signals and HDMI output
that is compatible with most HDMI-compliant devices.
© 2013 Advanced Micro Devices, Inc. AMD Radeon™ HD 7790 Graphics
