Sample Display Configurations
Once your displays are connected, you can control how they are configured using
the Radeon™ Software Adrenalin software application that is available with your
Radeon™ VII graphics driver. By configuring AMD Eyefinity™ technology using
Radeon™ VII Settings, you can also multiply your screen area to allow for immersive
gameplay or larger work spaces.
Sample Display
Configuration
DP Connector DP Connector DP Connector DP Connector Total
Output
DP-DP-DP-DP-
DP-DP
2 x DP 1.2 with
Multi-stream
2 x SP 1.2 with
Multi-stream
Native Native 6
DP-DP-DP-DP Native Native Native Native 4
DP-DP-dDVI Native Native DP to DVI (A) DP to DVI (A) 4
DP-DP-VGA-VGA Native Native DP to VGA (A) DP to VGA (A) 4
DP-DP-dDVI-VGA Native Native DP to VGA (A) DP to VGA (A) 4
DP-DP-HDMI Native Native DP to HDMI
(P)
No connection 3
dDVI-VGA-HDMI DP to DVI (A) DP to VGA (A) DP to HDMI
(P)
No connection 3
DP-dDVI-sDVI Native DP to DVI (A) DP to HDMI
(P)
No
connection
3
DP-DP-sDVI Native Native DP to DVI (P) No
connection
3
sDVI-sDVI DP to DVI (P) DP to DVI (P) No
connection
No
connection
2
HDMI-HDMI DP to HDMI
(P)
DP to HDMI
(P)
No
connection
No
connection
2
