Quad Processors
1
ADQUAD27 /
ADQUAD27-1
ADQUAD77 /
ADQUAD77-1
ADQUAD47 /
ADQUAD47-1
ADQUAD87 /
ADQUAD87-1
Camera Type B&W Color B&W Color
Time/Date/Title Single (monitor out only) Dual (monitor and VCR)
Remote Control N/A RS-232
Zoom on Playback N/A Yes
Video Input Channels Four
Video Loop Through Yes
On-screen Setup Yes
Alarm Sensor Type Normally Open (NO)/Normally Closed (NC); (Selectable)
Alarm Inputs Four
Alarm Call Full Screen Yes
Individual Dwell Yes
Security Lockout Yes
Rack Mount Fits standard 19” rack; single and dual kits available (optional)
Video Output Monitor: 1 V p-p; VCR: 1 p-p; Loop: 1 V p-p
Time/Date/Title Built-in clock with backup power; 8 characters for each title
Alarm Output NO and NC contacts: 1 Amp @ 24 VDC maximum
Alarm Duration Adjustable; 1 second to nonstop
Camera Dwell Adjustable; 1 second to 99 seconds
Remote Control N/A 1 to 9 units addressable
Refresh Rate 30 (NTSC/EIA); 25 (PAL/CCIR)
Resolution 512x512 (full screen) 1024x512 (full screen)
Number of Colors 256 gray scale 16.7M colors 256 gray scale 16.7M colors
Power Consumption 7.5 to 8.5 watts at 10V to 14V DC
Dimensions 215Wx309Dx44H (mm); 8.5Wx12.2Dx1.75H (in)
Operating Temperature 0° to 45°C or 32° to 113° F
