2 8000-1658-02, Rev. C American Dynamics
AD T
OUCH
T
RACKER
Installation Instructions
FOR CONNECTIONS LESS THAN OR EQUAL TO 4M (14 FT)
J3 Wiring
PIN
FUNCTION
24 Vac A
24 Vac B
Ground
2
3
4
4 3 2
EIM
J1
J3
J2
TRANSFORMER
24 Vac A
24 Vac B
Ground
RJ45
RJ45
TOUCH
TRACKER
AD SWITCH
VCR
IN
RS232
120V
60Hz
MONITOR
EXPAND
QUAD
ALARMS
RJ45
5 4 2
RJ45 Wiring
PIN
COLOR
GREEN
ORANGE
RED
5
4
2
DB9 (M)
5 3 2
DB9 (M) Wiring
PIN FUNCTION
Rx
Ground
Tx
3
2
5
COLOR
GREEN
RED
ORANGE
