American Dynamics 79
ADTVR Embedded Digital Video Recorders
ADTVR COMPARISON CHART
ADTVR ADTVR-VS
Video Inputs 4, 8, and 16 4
Audio Inputs 4, 8, and 16 1
Alarm Inputs 4 Ch 4
Alarm Inputs 8 & 16 Ch 16
4
Alarm Outputs 4 Ch 2
Alarm Outputs 8 & 16 Ch 4
1
Compression H.264 H.264
Looping Video Outputs Yes No
Video Spot Monitor 1 (route alarms to spot monitor) 1
USB 2.0 31
DVD RW Yes No
HDD 4 Ch 4 SATA
HDD 8 & 16 Ch 8 SATA
1 SATA
Network 4 Ch 1 RJ45 10M/100M NIC
Network 8 & 16 Ch 1 RJ45 10M/100M/1000M NIC
1 RJ45 10M/100M NIC
Chassis 19” Rack Mount Small Chassis (Single HDD)
Dimensions (H x W x D)
95 mm x 450 mm x 450 mm
(3.7 in x 17.7 in x 17.7 in)
45 mm x 315 mm x 230 mm
(1.8 in x 12.4 in x 9.1 in)
Compression H.264 H.264
Frame Rate 4 Ch
CIF: 30ips(NTSC); 25ips(PAL)
2CIF: 30ips(NTSC); 25ips(PAL)
4CIF: 8ips(NTSC & PAL)
Frame Rate 8 & 16 Ch
CIF: 30ips(NTSC); 25ips(PAL)
2CIF: 30ips(NTSC); 25ips(PAL)
4CIF: 12ips(NTSC & PAL)
CIF: 30ips(NTSC); 25ips(PAL)
2CIF: 12ips(NTSC & PAL)
4CIF: 6ips(NTSC & PAL)
Simultaneous Playback 4 Ch 4 Channel Playback (local)
Simultaneous Playback 8 & 16 Ch 8 Channel Playback (local)
1 Channel Playback (local)
Email Notification Yes No
File Lock Yes No
Reverse Playback Yes No
