Pre-Installation
Locate the packing list (located in the accessory box) and ensure that all items listed are present and accounted
for. If you determine that an item is missing please contact the factory prior to install.
Electrical & Refrigeration Requirements
AP20BC-1T
AP20BC-2T
AP20BC-3T
AP26BC-1T
AP26BC-2T
AP26BC-3T
AP36BC-1T
AP36BC-2T
AP36BC-3T
AP46BC-1T
AP46BC-2T
AP46BC-3T
AP20BCF-1T
AP20BCF-2T
AP20BCF-3T
AP26BCF-1T
AP26BCF-2T
AP26BCF-3T
AP36BCF-1T
AP36BCF-2T
AP36BCF-3T
AP46BCF-1T
AP46BCF-2T
AP46BCF-3T
Model
Cabinet
Electrical
Refrigeration BTU/H
Required*
Refrigeration Type
Required
Cabinet
Amp Draw
208/60/1
208/60/1
208/60/1
208/60/1
208/60/1
208/60/1
208/60/1
208/60/1
208/60/1
208/60/1
208/60/1
208/60/1
208/60/1
208/60/1
208/60/1
208/60/1
208/60/1
208/60/1
208/60/1
208/60/1
208/60/1
208/60/1
208/60/1
208/60/1
8.2 A
15.5 A
22.7 A
8.2 A
15.5 A
22.7 A
8.2 A
15.5 A
22.7 A
8.2 A
15.5 A
22.7 A
8.2 A
15.5 A
22.7 A
8.2 A
15.5 A
22.7 A
8.2 A
15.5 A
22.7 A
8.2 A
15.5 A
22.7 A
Medium Temp
Medium Temp
Medium Temp
Medium Temp
Medium Temp
Medium Temp
Medium Temp
Medium Temp
Medium Temp
Medium Temp
Medium Temp
Medium Temp
Medium/Low Temp
Medium/Low Temp
Medium/Low Temp
Medium/Low Temp
Medium/Low Temp
Medium/Low Temp
Medium/Low Temp
Medium/Low Temp
Medium/Low Temp
Medium/Low Temp
Medium/Low Temp
Medium/Low Temp
28,000
56,000
84,000
34,000
68,000
102,000
44,000
88,000
132,000
70,000
120,000
180,000
28,000
56,000
84,000
34,000
68,000
102,000
44,000
88,000
132,000
70,000
120,000
180,000
Condensing Unit Installation
The condensing unit must be installed and connected in accordance with the installation manual provided with
the condensing unit.
The condensing unit and the cabinet must be connected to separate electrical power supply.
When the condensing unit is provided by a third party, verify that rating meets the requirements listed above.
The blast chiller refrigeration system is of pump down type. The blast chiller controller will control the refrig-
eration by closing and opening the solenoid valve located inside the blast chiller cabinet. For proper operation,
make sure the low pressure controller is set to cut out at 4PSI and cut in at 15PSI.
2
*Rating at 14°F SST and 105°F condensing temperature
