INSTALLATION
CATCH
RETAINING ARM
STEP FOUR: INSTALL THE DOOR
K. Install the door and open the door completely.
L. Rotate the catch over the retaining arm on each hinge.
(Install the oven racks and close the oven door)
BURNER CAP
BURNER HEAD
GRATE
DESIGNED & BUILT IN USA
PROFESSIONAL COOKING EQUIPMENT
11
STEP FIVE: INSTALL THE BURNERS AND GRATES
CUISINE:
M. Install burner heads and burner caps on the pre-installed burner bases.
N. Remove grates from packaging and inspect them for rubber feet. Place the grate on top of grate support.
K L
N
M
BURNER BASE
BURNER CAP
BURNER HEAD
GRATE
BURNER CAP
BURNER HEAD
GRATE
