Ameriwood 5945307T - Page 9

2
step
9
Proper orientation of CAM LOCK
(1) x2
cam lock
(2) x4
cam bolt
(3)
x2
wood dowel
(8)
x12
#6 x 7/16" screw
(13)
x4
right cabinet slide
1
3
1
3
2
B
2
8
8
8
8
2
2
8
8
8
8
8
8
8
8
8
2
13b
13b
13b
13b
13b
13b
marked with an "R"
finished edge
1. Screw-in cam bolts must be screwed down flush.
2. Refer to page 7 for instructions on how to use the cam lock system.
