Page 9<&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1Item 64019
?@<6ATVX6;@ACVED@CEA6E@EQ6 ?6AFX
W,$,%B&79
The data hold function keeps the current reading on the Display. To activate data hold:
1. Press the BVGW button and
the reading will be held on the
Display. The %symbol appears.
2. Press BVGW again to release the hold.
U,4[7"3.$
1. Press the button to turn on the
Display backlight for 60 seconds.
2. Press the button a second time
to turn the Display backlight off.
E&$*- Frequent use of the backlight
shortens the life of the batteries. Only
use the backlight when necessary.
EQ!%cE&8KQ&8$,4$%!&7$,3*d
1. Turn Rotary Switch to any position.
2. Hold the EQ! button and move the
Non-Contact Voltage Sensor close to
the unshielded conductor. If detected
voltage is >110V AC, Meter will beep
and the Non-Contact Voltage Indicator
will flash.
R@;ECESb 6Y*8%"2%8&%"89"4,$"&8%"#%
3"Y*8I%Y&7$,3*%5,>%#$"77%+*%/(*#*8$1
Do not rely solely on NCV detection to
determine the presence of voltage.
@'$&%X&)*(KV22
If the Meter is not used for approximately 15 minutes, it automatically turns itself off
to conserve battery power. To turn the Meter back on after auto-off, press any button.
To disable Auto Power-Off, hold the <FEQ button while powering the Meter on.
U,(%S(,/.
The bar graph updates 10 times faster than the digital display. This can
be used for monitoring changes in measurements at a higher sampling
rate. The bar graph indicates polarity (K) and overload ( ).
