AMES 64018 - Page 10

Page 10 <&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1 Item 64018
?@<6AQ RS6;@ACRE D@CEA6E@ET6?6AFS
<(*H'*84>%D*,#'(*5*8$
Measure frequency up to 100kHz.
1. Turn the Rotary Switch
to the B[%position.
2. Connect the Test Leads across
the circuit to be measured.
3. Read measured frequency
on the Display.
4. When testing is complete, turn
Rotary Switch to R<<%and store Meter.
T,/,4"$,84*%D*,#'(*5*8$#
Measure capacitance up to 100μF.
WARNING! Turn off all power and fully
discharge capacitors on the circuit
under test before measuring.
1. Turn the Rotary Switch
to the position.
2. Carefully touch capacitor
leads with tips of probes.
3. Read measured capacitance
on the Display.
4. When testing is complete, turn
Rotary Switch to R<< and
store capacitor and Meter.
T'((*8$%D*,#'(*5*8$
Measure AC and DC conductors
carrying up to 400 milliamperes.
E&$*- Amperage is always tested
in series with circuit under test.
1. Turn the Rotary Switch to the
5@ position.
2. Press ?6G6TA button to choose
between AC and DC current.
3. Connect the Test Leads across
the circuit to be measured.
4. Read measured frequency
on the Display.
5. When testing is complete, turn Rotary
Switch to R<< and store Meter.
