Amewi ARROW 5 - Page 10

10
amewi.com
13 Silicon tube
26
Lipo battery
No.
Name Name
Hull
Name
1 Cabin outer cover
14
27
Battery board holder2 Cabin inner cover
15 Support bracket
28
Pressure water pieces3 EVA waterproof ring
16 Rubber stopper
29
O-ring press pieces4 Boat surface
17 Rod
30
Right navigation5 Steering gear retainer
18 Rod waterproof ring
31
Left navigation6 Steering gear
19
32
Rod retainer7 Spindle tube holder
20
Spindle tube
8 Steel rope holder
21
Teflon tube Tail rudder rocker arm
9 Brushless motor
22
Anti-slip nuts
10 Outlet plugs
25
Propeller
2311 Receiver box Propeller holder
No. No.
2412 ESC case Steel rope
33
34
Tail rudder
Tail rudder support bracket
35 Left water press
36 Right water press
Steering knob
Throttle trigger
Transmitter
Forward trim
Backward trim
Power indicator
Left Rudder trim
Right Rudder trim
Power switch
Steering knob
Throttle trigger
Button Function
Press down this button to adjust the throttle forward deviation.
Press down this button to adjust the throttle backward deviation.
Press down this button to adjust the tail rudder left turning deviation.
Press down this button to adjust the tail rudder right turning deviation.
Push right to power on the transmitter, and back to power off.
Twist forward the knob, the boat turns right. Twist backward the knob,
then turn left.
Pull down the throttle trigger and the boat goes forward. Push up the
trigger, then go backward.
Forward trim
Backward trim
Left Rudder trim
Right Rudder trim
Power switch
