Amewi ARROW 5 - Technical Specifications and Troubleshooting

19
Circuit diagram
amewi.com
-
+
Voltage detection line
Power supply / signal line
Steering gear line
Lipo battery
Steering gear
Receiver
Power supply / signal
line ( line 3 )
Voltage detection
line ( line 1 )
Steering gear signal line
黑色线
红色线
黄色线
Power line
Yellow line
Red line
Brown line
s
CBA
