Step of installing protective cover:
O. Install floor cover (See Fig 33).
2. Install the protective
cover and tight up the
head cup bolt
Wire of hydraulic
solenoid valve
Wire of motor
Wire of limit switch
Oil hose for
power unit
Fig. 32
1. Screw the head
cup bolt M6*40
wind around
wire
