30
CLEANING AND MAINTENANCE
Removal of the internal glass panel
Replacing the halogen bulb in the oven
Before replacing the halogen bulb, make
sure the appliance is disconnected from
the electric mains to avoid a possible
electric shock.
Oven lighting
1. Unplug the appliance
2. Remove shelves and trays from the oven.
3. Unscrew and wash the lamp cover and
then wipe it dry.
4. Pull the halogen bulb out using a cloth
or paper. If necessary, replace the halogen
bulb with a new one.
- voltage 230V
- power 25W
5. Replace the halogen bulb in its socket.
6. Screw in the lamp cover.
3. Pull the inner glass panel from its seat
(in the lower section of the door).
Important! Risk of damage to glass
panel mounting. Do not lift the glass
panel up but pull it out.
Remove the inner panel (g. D).
4. Clean the panel with warm water with
some cleaning agent added.
Carry out the same in reverse order to
reassemble the inner glass panel. Its
smooth surface shall be pointed up-
wards.
