#650000 HD450/ #670000 EXT 350 PARTS LIST - AMI0071239 TO PRESENT
Part# Description Qty/Unit Part# Description Qty/Unit
1025 Bushing w/ Shoulder, 1 1/16 ID x 1 3/16 OD 1
1036 Collar Stem 1
1081 Bushing 1 3/16 OD x 1 Lg 1
1192 Washer, Flat, 9/32 ID x 5/8 OD 8
1253 Nut, Hex, Keps, 5/16-18 1
1254 Pin, Spring, 1/8 OD x 1 1/8 Lg 1
1344 Screw, Hex, 1/4-20 x 1 1/2 Lg 6
1444 Knob, Arm Adjustment 2
1450 Screw, Hex, 5/16-18 x 2 1/2 Lg 1
2237 Nut, Hex, 3/8-24 1
2822 Screw, Hex, 1/4-20 x 1 3/4 Lg 4
3083 Nut, Hex Serrated Flange, 1/4-20 10
4075 Screw, Flat Head Hex Socket, 1/4-20 x 2 Lg 2
4953 Screw, Hex, 1/4-20 x 2 1/2 Lg 4
5190 Screw, Hex Socket, 1/4-28 x 3/8 Lg 1
6191 Post, Lower Seat 1
6463 Plug, Round, 7/8" OD 2
6505 Screw, Hex, 3/8-24 x 4 1/2 Lg 1
6993 Bracket, Cord Reel 1
7281 Screw, Hex Socket, 1/4-20 x 7/8 Lg 2
7361.30 Pot Asm, Health Care 1
7441 Circuit Breaker, Auto Reset, 25 Amp 1
7541 Wheel, Stability, 1 5/8 2
7599 Rivet, Truss Head, 1/4 OD x 1 1/2 Lg 4
7600 Nut, Push, 1/4 Stud 4
7773 Cap, Vinyl Insulated 2
7852.10 Wire Asm, Charger To Controller 1
8216 Charger, 3 Amp 1
8223.16 Enclosure, Hi/Lo w/ Battery Display 1
8300 Strap, Battery Retaining 1
8417 AC Cord Reel 1
8534 Plug, Tube Square, 1" 2
8669 Tube, Rear Bumper 1
8670 Bracket, Bumper Wheel 2
8675 Ground Wire Asm 1
8694 Bumper Asm Rear 1
8944 Band, Controller and Charger Mounting 4
8969 Cable, MPC Handle Control 1
9250 Arm Asm, Right, 2" Higher Removable 1
9251 Arm Asm, Left, 2" Higher Removable 1
9497 Seat Asm, Black Vinyl, 22 Inch 1
9766 Wire Asm, Battery To QC 2
9768 Wire Asm, Battery QC To Controller 1
9856 Arm Asm Set Flip-Up Adjustable 2" Higher 1
9936 Handle, Upper 1
9950 Lever, Handle Adjustment 1
9983.30 Seat Lock Asm, RH, 20" & 22" Seats 1
9983.31 Seat Lock Asm, LH, 20" & 22" Seats 1
10050 Bearing Set 1
10289 Basket, Front 1
10301 Bellows, Cover, Arm Rest 2
10335.20 Column Asm, Red, EZ-Tilt 1
10347.20 Seat Asm, Vinyl, 20" w/ Pouch 1
10511 Fork Weldment, Front 1
10514 Mat, Standard 1
10516 Boot, Lower Handle 1
10539 Light, Front, Hi/Lo 1
10554 Clip, Wire Guide 3
10568 Trim, Bumper, HD 1
10571.20 Bracket Asm, Basket 1
10585 Hub Cap, Mag Style Wheel 2
10595 Platform, Extended, Red 1
10690 Wheel 9" Front 1
10940HD Controller, HD 450 1
10976 Clip, Wire Guide 5
10980.20 Seat Asm, Cloth Back 1
11043 Drive Asm, Heavy Duty, 24 V 1
11081.20 Post, Upper Seat HD 1
11087 Brake Asm, w/ Microswitch 1
11174 Clamp, Motor 2
11175 Wheel Asm, 10 Inch w/ Keyway 2
11236 Motor Asm w/o Brake 1
11264 Bracket Charger/Controller 2
11289 Wire Asm Interface, Controller 1
11311 Washer, Lock, 1/4 ID 4
11355 Screw, Phillips, #6 x 1 1/2 Lg 4
11466 Plate, Back, Standard, Ez Tilt 1
210203 Arm Pad Single Molded 2
210204 Arm Pad Pair Molded 1
267001 Stem Collar Screw & Nut 1
269002 Battery, 12 Volt, 33 AH (U-1) 2
300514 Cover Asm, Rear, Red, HD 450 1
To Next Page
