Amigo RD Operational Manual

Adjusting Seat Height
Without a Power Seat Lift
To raise or lower your seat height, remove the nut and screw that
holds the seat collar in place on the seat post, then adjust and reinstall
in the desired hole on the seat post (Figure 2).
IT IS RECOMMENDED THAT THE SEAT LOCK BE INSTALLED IN THE
SECOND HOLE POSITION FROM THE SEAT ON A FOLDING SEAT
AND THE PREMIER II SEAT.
Seat Lock Lever
This allows the seat to rotate 360 degrees and lock in any position desired. The seat lock lever
is a bar with a vinyl cap on its end, located under the right or left side of the seat. Push the
lever forward to rotate to any position. Lock seat during vehicle operation.
Adjustable Armrest Width
The armrest width is determined by loosening the armrest knobs
and tightening them when the arms are at the desired width.
Flip Up Armrest
By pulling up on the end of either armrest, the armrest will flip back
for easy transfer in and out of the Amigo.
OPERATING YOUR AMIGO
To operate your Amigo, use the following procedures:
• ForallAmigoreardrivemodels,thekeyswitchislocatedonthe
top of the handle. Insert and turn the key provided.
• HI/LO:Adjustthespeedadjustmentknobtominimum(turn counterclockwise).
• TOUCHTRON:Adjustthespeedtominimum(press turtle button).
• PresstheforwardacceleratorleverorthereverseacceleratorlevertomovetheAmigo.
To move forward, pull the right side of the accelerator lever toward you (Figure 3).
You can also move forward by pushing the left side of the accelerator lever away
from you. To operate in reverse, pull the left side of the accelerator lever toward
you (Figure 4) or push the right side of the accelerator lever away from you.
Note: For optional “reverse polarity” handles, accelerator lever operation will be
the opposite – to move forward, pull the left side of the accelerator lever toward
you or push the right side accelerator lever away from you. To move in reverse,
pull the right side of the accelerator lever toward you or push the left side
accelerator lever away from you.
• Tostop,justreleasetheacceleratorleverandthevehiclewillcometo
a gradual stop within a few seconds after release.
• WhentheAmigoisusedatnight,youcanturnthelightson
by pressing the light button (TouchTron only).
• Allmodelsareequippedwithamanualbrakereleaselever.
To engage the freewheeling mode, push the brake lever
forward. The freewheeling mode will allow you to push the unit,
if necessary. To terminate the freewheeling mode, pull the brake lever
toward the rear of the Amigo (Figure 5). When pulled into “normal,”
the vehicle will be back into “drive” mode.
Manual brake
lever (Inside)
6 www.myamigo.com
Figure 2
Figure 5
Figure 3
Forward
Figure 4
Reverse
