6 ASC 70 / 90 / 100 / 110 / 130 / 150 / 200 / 250
1. Introduction
The roller should be used under conditions dened in the Czech Standard (CSN) IEC 721-2-1 (038900): WT, WDr, MWDr, i. e. in mild, dry
warm and dry hot weather in the range of temperatures from -15 °C (5 °F) to 45 °C (113 °F).
If the machine is used incorrectly, by untrained operators or for other purpose than stipulated above, there is a danger of an accident
or damage to the equipment.
Some expressions are used in the manual for better orientation, i. e. right, left, forward, backward – in the sense of the machine mov-
ing forward.
This Service Manual splits into separate chapters, it includes technical data and assembly data, adjusting
guidelines, and instructions to use special tools, jigs and aids.
The major purpose of this Workshop Manual is to provide basic information on disassembly, assembly and
service repairs of the Machine’s main groups.
Machine group identication in this Manual corresponds to the Spare Parts Catalogue.
Before the assembly, itself, we recommend to always mark the parts disassembled, and this due their reas-
sembly, and to blind all the holes of individual parts of the hydraulic system so to prevent any contamination
of the hydraulic circuits.
When you install individual parts into the Machine, please tighten individual bolts or nuts as per the torque
tables (Annex) unless otherwise stated in the text.
ALWAYS observe safety instructions and precautions mentioned in Chapter 2.
Manufacturer improves continuously his products based on operation experience and latest knowledge.
Consequently, Manufacturer reserves the possibility of changes depending on development, and this against
the illustrations, descriptions, procedures or design patterns given in this Manual.
