5. Description of the machine
Vibrating roller is a self-movable compaction machine consisting of two parts connected with a joint, i. e. drum and towing unit.
Drum unit
consists of the frame in which the drum with the travel drive and vibration drive is placed. Owing to two amplitudes of dierent -
size, which can be chosen together with the corresponding frequency, it is possible to compact materials of dierent charac-
teristics. Two scrapers placed in the front side on the beam and in the rear side on the cross bar of the drum frame are used for
removing the soil adhering to the drum.
Trailing hinge
connects both units of the roller and enables mutual shift of the parts in horizontal and vertical planes. -
Frame of the towing unit
welding, in its front part there is a plate for gripping the joint, holes where hydraulic motors of the travel are installed, in the -
rear part there is a fuel tank with grips for batteries and a toolbox. Holes for gripping the hydraulic tank, driver’s station and
protective ROPS frame are situated in the upper part of the equipment.
Version
Vibrating roller ASC 70 ÷ 250 D
This kind of roller with a smooth drum is suitable for compacting all sorts of earth, rock-ll and aggravate materials.
Vibrating roller ASC 70 ÷ 250 PD
This type of roller with a pad footed drum has a simultaneous compacting and vibrating eect on clay and mixed soils.
Vibrating roller ASC 70 ÷ 250 PDB
This type of roller with a pad footed drum PD and the blade (earth-board), moreover, of spreading made-up material.
Sign the machine with index HD
Machine with increased traction force.
Sign the machine with index HT
Machine with increased traction force. The machine is made for permanent operation on slopes over 30 % in extreme conditions.
Attached equipment
Pad-foot segments
The attached equipment installed on the smooth drum partially substitutes the pad-footed drum.
Blade (earth-board)
The attached equipment serves for spreading bulk soil and for its leveling in the area being compacted. The arms of the blade are
pendulum xed to the frame of the drum. The blade is lifted and lowered using two linear hydraulic motors xed into brackets on the
right and left side beams of the drum.
The ROPS protective frame
It protects the driver in case of overthrow of the machine. The data about the frame are shown in the plate.
ASC lock - CASE / ATC lock - AMMANN
It features the ability to pass well through a rough terrain (gradient) at decreased adhesion, at running to the trailer, it helps to free the
machine, etc.
Filling of tires with liquid
