58 ASC 70 / 90 / 100 / 110 / 130 / 150 / 200 / 250
5. Description of the machine
Fluid contents
ASC 70/90
Engine (oil lling) Tier 1 and Tier 2 l [gal US] 11,2 [2.96]
Engine (oil lling) Tier 3 l [gal US] 7,0 [1,85]
Cooling system Tier 1 and Tier 2 l [gal US] 19,0 [5.0]
Cooling system Tier 3 l [gal US] 24,0 [6.3]
Fuel l [gal US] 275,0 [72.7]
Hydraulic system l [gal US] 73,0 [19.3]
Drum gearbox (HD) l [gal US] 2,5 [0.66]
Drum gearbox (HT) l [gal US] 2,8 [0.74]
Wheel gears l [gal US] 2x2,5 [2x0.66]
Vibrating drum l [gal US] 6,7 [1.77]
Windshield washer bowl l [gal US] 2,75 [0.72]
ASC 100
Engine (oil lling)
l [gal US] 11,2 [2.96]
Cooling system l [gal US] 24,0 [6.3]
Fuel l [gal US] 410,0 [108.3]
Hydraulic system l [gal US] 90,0 [23.8]
Drum gearbox l [gal US] 3,5 [0.92]
Wheel gears l [gal US] 2x2,5 [3,3x0.87]
Vibrating drum l [gal US] 8,0 [2.1]
Windshield washer bowl l [gal US] 2,75 [0.72]
ASC 110/130/150
Engine (oil lling) Tier 1 and Tier 2 l [gal US] 16,3 [4.3]
Engine (oil lling) Tier 3 l [gal US] 11 [2.9]
Cooling system Tier 1 and Tier 2 l [gal US] 25,0 [6.6]
Cooling system Tier 3 l [gal US] 32,0 [8.5]
Fuel l [gal US] 410,0 [108.3]
Hydraulic system l [gal US] 90,0 [23.8]
Drum gearbox (ASC110/130 HD) l [gal US] 4,2 [1.11]
(ASC110/130HT; ASC150HD) l [gal US] 4,8 [1.27]
(ASC150HT) l [gal US] 5,1 [1.36]
Wheel gears l [gal US] 2x2,8 [2x0.74]
Vibrating drum l [gal US] 8,0 [2.1]
Windshield washer bowl l [gal US] 2,75 [0.72]
ASC 200/250
Engine (oil lling) l [gal US] 14,3 [3.78]
Cooling system l [gal US] 30,0 [7.9]
Fuel l [gal US] 405,0 [107.0]
Hydraulic system l [gal US] 100,0 [26.4]
Drum gearbox l [gal US] 7,7 [2.0]
Wheel gears l [gal US] 2x4,4 [2x1.2]
Vibrating drum l [gal US] 7,5 [1.98]
Windshield washer bowl l [gal US] 2,7 [0.71]
Cooling system of the Drum l [gal US] 185 [48.9]
