Ammann ASC 130 - Page 79

75ASC 70 / 90 / 100 / 110 / 130 / 150 / 200 / 250
ASC133
1
ASC134
53
ASC132
ASC131
WORKSHOP MANUAL
Disconnect control unit of engine T2, T3 for ASC 110÷250.
Disconnect intake and overow of fuel.
Lift the cabin using hydraulic lift, then use crane to unload the
piston of the lifting hydraulic motor using xture no.1.
Remove bolts 53.
Set rubber wall aside.
