330 ASC 70 / 90 / 100 / 110 / 130 / 150 / 200 / 250
24. Hydraulic
Hydraulic circuit – ASC110/130/150 - Interaxle dierential lock ATC
for ASC 110 since serial number 1335
for ASC 130 since serial number 128
for ASC 150 since serial number 853
Diagram:
1 - Travel hydrogenerator SAUER
2 - Vibration hydrogenerator
3 - Drum travel hydromotor SAUER
4 - Vibration hydromotor
5 - Wheel travel hydromotor SAUER
7 - RTM Module REXROTH
8 - Steering hydrogenerator REXROTH
9 - Power-assisted steering REXROTH
10 - RTM control block HYTOS
11 - Linear hydromotor - steering AXL SEMILY
12 - Brake block HYTOS
13 - Pressure switch HYTOS
14 - Suction strainer HYTOS
15 - Filter DONALDSON
16 - Filler neck ARGO
17 - Level indicator
18 - Cooler combined-type EMMEGI
19 - One-way valve HYTOS
20 - Thermoregulator
21 - Quick-coupler for measuring STAUFF
22 - Quick-coupler for lling - male FASTER
23 - Quick-coupler - female FASTER
24 - Quick-coupler - male FASTER
25 - Thermometer sensor
26 - SMA 03 lifting unit HYTOS
27 - RC16 manual lifting unit
28 - Lifting block HYTOS
29 - Hydraulic lock HYTOS
30 - Linear hydromotor - cab lifting AXL SEMILY
31 - Linear hydromotor - bonnet lifting AXL SEMILY
