AMP 1200 Quick Reference Guide
1
2
3
4
5
LCD display
NFC contactless reader
Keypad
PIN privacy shield
Indicator LEDs
1 Introduction
The AMP 1200 secure NFC PINpad is designed to instantly add contactless and PIN
enabled payments to any existing POS systems. Merchants can easily connect the 1200
terminal via Micro USB or RS232 to rapidly and affordably expand their payment
acceptance ability, while the EMV and PCI PTS 5.0 certifications mean they can accept
payments with confidence. Featuring a 1.7” backlit LCD and adjustable display elements
such as scaled text and images, the terminal can be modified to fit any merchant’s payment
flow to include content directly aimed at key customers. Optional customizations such as
the biometric fingerprint scanner and three programmable function buttons further allow
the AMP 1200 to expand and enhance existing point of sale payment options.
2 AMP 1200 Architecture
2.1 Top View
2
4
5
3
1
