Advanced Mobile Payment Inc. www.amobilepayment.com
AMP 1200 Quick Reference Guide
Nothing displayed
on screen
Contactless card
data read error
Ensure the power is properly connected at both ends of the cable
Confirm that the card supports contactless communication
Check whether the card is properly aligned above the contactless reader area
Problem Troubleshooting
PROCESSOR
MEMORY
DISPLAY
CONNECTIVITY
32-bit secure processor,
4 MB flash, 512 KB RAM
Micro USB, 4P4C RS232
EMV contactless level I, PCI PTS 5.0, Mastercard Contactless, Visa Paywave
CERTIFICATION
CARD READER NFC, ISO4443 A/B, Mifare
OTHER Optional built-in speakers, Buzzer with warning tone, voice function support
SECURITY
Master/Session and DUKPT Key Management
10 alphanumeric keys, 3 function keys
Optional fingerprint scanner
1.77 “ 128 x 160 backlit LCD, 4 color LED indicator lights
POWER 5V DC, 1A
(157x82x71mm) - (6.2x3.2x2.8”) LxWxH PHYSICAL
BUTTONS
BIOMETRICS
O°C ~ 50°C (32°F ~ 122°F), 10% -90% humidity (non-condensing)
-20°C ~ 60°C (-4°F ~ 140°F), 5% -95% humidity (non-condensing)
OPERATION
230 g (0.5 lbs)
WEIGHT
STORAGE
If problems occur with the terminal, try these simple troubleshooting methods to correct
the fault, or contact a service representative to further diagnose the issue.
6 Troubleshooting Common Problems
5 Technical Specifications
The following are specifications detailing the overall capabilities of the AMP 1200, including
optional or variable elements. To obtain the specifications for your individual terminals, refer
to the original sales order or your sales representative for more information.
If problems persist after completing these troubleshooting procedures, please contact your
sales or service representative. Do not attempt to open the terminal or make further repairs.
